Conical rotor, Squirrel Cage, 1 hr. Rated, Class 'F', Insulated crane duty motor. |
• |
Electromechanical, Conical disc type, 100% failsafe maintenance free Brake, eliminates need of coil & thereby coil burning and down time problems. |
• |
Easily portable because of compact design and low weight |
• |
Wear-resistant, Heat-trated, Grade 80, Special alloy steel calibrated load chain. |
• |
A special conical friction clutch housed inside the gearbox, protects the hoist against overloading.
It also works as Emergency limit stop and protects overhoisting and over lowering |
• |
Specially designed Chain guide enables Smooth, Jerkless, Free and Silent running of Chain over the
Load Chai n sprocket |
• |
TOTALLY ENCLOSED, BUILT-IN PANEL BOX containing Air Break contactors for Hoisting and
Lowering motion and control transformer to get a Control voltage of 110 Volts IS AN INTEGRAL
PART OF THE HOIST. |
• |
All Gears are made of Carbon / Alloy steel, high precision cut, hardened and tempered, and are mounted
on antifriction bearings. |
• |
Hoist is supplied with a pendant push button station and a two mtrs. Long pendant cable. Additional
cable lengths are available on request. |
• |
Hoist is supplied with a 3 mtrs. Long power supply cable. Extra length can be supplied on request. |
• |
Hoist is supplied with Chain for three mtrs. Height of lift. Additional chain can be provided for higher
height of lift, on request. |
